Watchdog NTC to F500 PGW CAI REV0 July 2014
F500 FIELDBUS ADAPTER.
INTRODUCTION
This version of the F500 Elite Fieldbus adapter had been designed to work as a Watchdog
Elite communications gateway and has been designed specifically to allow up to 7
Watchdog NTC control units to be networked together through their own built in
communications system. The network data can then be passed through the Fieldbus
adapter to a Profibus DP network. The communications control unit is housed in a self-
contained wall-mounting enclosure, and will operate from 100-240v AC or from 24v DC.
1. SPECIFICATIONS
1.1 The Control Unit
A plastic enclosure houses the electronics and terminal connectors. The unit contains a
printed circuit board to accommodate power supply circuitry, microprocessor, Fieldbus
card and terminals. The design is capable of accommodating 8 of the most common
Fieldbus interfaces.
Electrical Supply – 100-240VAC +/- 10% 50/60Hz
- 24VDC +/- 10%
Power Consumption - 12 WATTS
Terminals - Power 4mm² 14 AWG max
- Communications, as appropriate to the Fieldbus
module.
Protection - NEMA4X,IP66
Height - 9.7”, 246mm
Width - 7.4”, 188mm
Depth - 4”, 102mm
Fixing Centres - 8.75” high x 4” wide, 222mm x 102mm
Cable Entry - 2 Holes 11/8” DIA, 28mm, ¾” CONDUIT
Weight - 3lbs, 1.3Kg
Approvals
For V4 Model
1180 Ex tb IIIC T125° Db IP66 T
AMB
-20°C to +50°C IECEx BAS05.0026X
1180 Ex II 2D Ex tb IIIC T125° Db IP66 T
AMB
-20°C to +50°C Baseefa04ATEX0131X
CSA - Class II Div. 1, Groups E, F & G
(F5004V4CAI-PGW - When Powered with a Class 2 Power Supply)
For V46 Model:
1180 Ex tc IIIC T125° Dc IP66 T
AMB
-20°C to +45°C IECEx BAS11.0018X
1180 Ex II 3D Ex tc IIIC T125° Dc IP66 T
AMB
-20°C to +45°C Baseefa11ATEX 0033X
CSA - Class II Div. 2, Groups F & G (F5004V46CAI-PGW)
