To Next PageTo Next PageWhat to do if the alarm/stop LED is blinking on 4B W4005V46-SYS/B Measuring Instruments?
If the Alarm/Stop LED is blinking but no alarm is present, it means that the unit is either not calibrated or is waiting for calibration. You should calibrate the W4005NV46CAI /B controller before using it. Refer to section 10.14 for calibration instructions.
What to do if the elevator is not stopping when alarm is present in 4B Measuring Instruments?
Verify that the motor started wiring is correct according to the drawings specified in Figure 14 of this manual.
Why is the bearing temperature sensor alarm always present on 4B Measuring Instruments?
The constant alarm could be due to several reasons: 1. Incorrect settings of switches 3 and 4 within SW2. Refer to section 10.13.2 - DIP Switches (SW2) for the correct setup. 2. Faulty or improperly greased bearings. 3. Faulty temperature sensors, which may need replacement.
How to fix immediate stop/shutdown after calibration of 4B W4005V46-SYS/B Measuring Instruments?
If your system stops or shuts down immediately after calibration, consider the following: * Check for any misalignment alarms. * Ensure the speed sensor detects speed (the output LED on the sensor should blink when the shaft rotates). * Verify that the motor contactor is wired exactly as shown in the manual.
What to do if sensor in alarm/fault in 4B Measuring Instruments?
If a sensor is in alarm or fault state: * Check if the sensor is in a state of alarm and clear it. * Ensure the sensor is receiving the correct power (+24VDC). * If necessary, replace the faulty sensor.
How to troubleshoot no power to sensors on 4B W4005V46-SYS/B Measuring Instruments?
If there is no power to the sensors: * Check that the field power fuses (F1 and F2) are not damaged. * Ensure the field wiring delivers +24VDC to the sensors. * Replace any faulty fuses and sensors as needed.
How to troubleshoot if the power LED is off on 4B W4005V46-SYS/B?
If the power LED is off, check the following: * Ensure power is applied to the unit on terminals 25-28. * Verify that the main input fuse F6 is not damaged. * Check that the internal circuitry fuse F5 is not damaged.
General| Brand | 4B |
|---|---|
| Model | W4005V46-SYS/B Series |
| Category | Measuring Instruments |
| Language | English |
Details on installing the TouchSwitch alignment sensor.
Installing the W400 Series Elevator Controller.
Important safety warnings for electrical installation.
Wiring instructions for the elevator controller unit.
Procedure for calibrating the W4005NV46AI/B controller.
Details on system alarms and shutdown conditions.
Table detailing Ethernet data allocation for output.
Detailed contact information for manufacturers.
