Receiver (RX)
A Channel
is Connected
B Channel is
not Connected
Mono Mode
Stereo Mode
Safety Mode
Receiver’s
Battery Level
A/B Channel Audio Dynamic Bar Output Gain
Mono Mode:
Output a mixed audio track of A channel and B channel.
Stereo Mode:
Output two independent audio tracks of A channel and B channel.
Safety Mode:
Output two mono audio tracks: One is normal audio, and the other is safe audio
reduced by -6dB on the basis of normal audio.
