909 DP250LS - Know Your Product

9
Know your product
1. Laser light on/off switch
2. Laser aperture (x2)
3. On/off switch
4. Pulley cover
5. Base
6. Column
7. Table/Support Assembly
8. Table Lock
9. Belt (x1)
10. Belt Tension Knob
11. Keyed Chuck
12. Motor Head
13. Feed Handle
14. Depth Scale
15. Depth Locking Knob
16. Bevel Scale
17. Chuck Key
18. Hex Keys (3mm, 4mm)
1
2
5
3
4
6
7
8
16
10
12
13
9
14
15
17
18
11
