909 PH1000 - Know Your Product

7
16
Know your
product
1. Motor housing
2. On/Off trigger switch
3. Lock off button
4. Main handle
5. Secondary handle
6. Shoulder strap
7. Main shaft
8. Extension shaft
9. Extension shaft clamp
10. Chain bar and chain
11. Oil tank
12. Drive sprocket cover
13 Spanner
14 Chain cover
15. Drive head
16. Chain tensioner screw
17. Chain cover screw
18. Chain oil tank cap
19. Chain oil tank
20. Chain bar cover
21. Drive sprocket
22. Chain stud
23. Tensioning pin
24. Chain
1
2
3
4
5
7
8
9
10
14
13
15
17
18
19
6
20
24
21
22
23
