Central Vacuum
• Plumbing up to the floor box utility center and its
termination point is to be specified by the central
vacuum supplier (terminates in the utility center).
• Wet systems:
○ Plumbing to terminate with 5/8" (16 mm) O.D.
tube protruding 1" perpendicular to the floor.
○ 10 ± 2 in Hg, 9 scfm minimum.
Gravity Drain
• 1-1/2" (38 mm) nominal pipe protruding 1" (25 mm)
from finished floor. Trap to be placed in line,
conforming to local codes, contractor-supplied.
• Floor mount only. Not recommended for wall
mount utilities.
Shipping Weights
Documentation References
Installation Guides:
○ A-dec 500 Install . . . . . . . . . . . . . . p/n 86.0400.00
○ A-dec 300 Install 300 Radius-Style
on an A-dec 511 Chair . . . . . . . . . p/n 86.0307.00
Service Guides:
○ A-dec 500 Service Guide . . . . . . . p/n 85.0816.00
○ A-dec 300 Service Guide . . . . . . . p/n 85.0818.00
○ A-dec 300 Service Guide
Supplement . . . . . . . . . . . . . . . . . . p/n 86.0273.00
Instructions for Use:
○ A-dec 500 Delivery Systems . . . . p/n 86.0607.00
○ A-dec 500 Assistant’s
Instrumentation . . . . . . . . . . . . . . p/n 86.0603.00
○ A-dec 500 Cuspidor . . . . . . . . . . . p/n 86.0604.00
○ A-dec 500 Chair . . . . . . . . . . . . . . p/n 86.0602.00
○ A-dec 300 Delivery Systems . . . . p/n 86.0092.00
○ A-dec 571/572/6300 Light . . . . . p/n 86.0612.00
○ A-dec LED Dental Light . . . . . . . p/n 86.0331.00
○ A-dec 371/372 Light . . . . . . . . . . p/n 86.0220.00
○ Regulatory and Specifications . . p/n 86.0221.00
○ A-dec Equipment IFU DVD . . . . p/n 86.0042.00
Full-Size Templates:
○ A-dec 500 Product . . . . . . . . . . . . p/n 86.0904.00
○ A-dec 500 Chair . . . . . . . . . . . . . . p/n 86.0905.00
○ A-dec 300 Radius-Style
on A-dec 511 . . . . . . . . . . . . . . . . . p/n 86.0312.00
○ A-dec 500 Floor Box . . . . . . . . . . . p/n 85.0472.00
NOTE Gravity drains are needed only on
systems with a cuspidor.
Product/Box Est. Shipping Weight
A-dec 511 Chair 401 lb (182 kg)
A-dec 532 Delivery System 60 lb (27 kg)
A-dec 533 Delivery System 72 lb (33 kg)
A-dec 334 Delivery System 53 lb (24 kg)
A-dec 335 Delivery System 55 lb (25 kg)
A-dec 561 Support Center
(w/cuspidor)
76 lb (34 kg)
A-dec 561 Support Center
(w/cuspidor, support link, and lower
support arm)
120 lb (54 kg)
A-dec 551 Assistant’s Instrumentation
(w/support link)
39 lb (18 kg)
A-dec 571/571L Dental Light 35 lb (25 kg)
A-dec 572/572L Dental Light 47 lb (21 kg)
A-dec 371 Dental Light 35 lb (17 kg)
A-dec 372 Dental Light 47 lb (21 kg)
531 Monitor Mount
(without monitor) 65 lb (29 kg)
561 Monitor Mount
(without monitor) 15 lb (7 kg)
Radius-Style Monitor Mount
(without monitor)
27 lb (12 kg)
NOTE Use only full-scale templates for
locating the plumbing and electrical.
NOTE The floor box mounting hole placements
appear on the floor box base that is being
installed.
