Touchpad
A-dec 500 Assistant’s Instrumentation
Page 10 86.0603.00
Dental Light
The dental light button on the touchpad works as a three-way switch allowing you to turn the dental
light on or off from either the touchpad or the dental light.
A quick press on the button allows you to toggle between three intensity settings, depending on the
location of the dental light’s intensity switch. The dental light can be toggled between composite and
medium intensity settings or composite and high intensity settings. When the dental light is in the
composite setting, the indicator light next to the button flashes.
The dental light also has an auto On/Off feature. When using a programmed chair position (1 or 2), the
dental light will come on when the chair reaches an operating position. The dental light will turn off
automatically when Position 0 (entry/exit) or Position 3 (x-ray/rinse) is pressed.
NOTE: If Position 3 has been reprogrammed to a programmable position, the dental light will not
turn On/Off when Position 3 is pressed.
How to Disable Factory Preset Functions
There are two factory preset options that can be turned On or Off from the standard touchpad.
Dental Light (Auto On/Off)
Auto On/Off setting can be turned off by pressing and holding the Program button and then the Light
button together for three seconds. One beep will confirm that the fatory preset has been turned off. To
return to the factory preset repeat steps. Three beeps will confirm that the auto On;Off function is on.
Position 3 (X-ray/Rinse)
Position 3 can be toggled from the x-ray/rinse position to a programmed position. To program Position
3, press Program and then press and hold Position 3 together for three seconds. One beep confirms that
the position can be programmed. To return to the x-ray/rinse position, repeat steps. Three beeps con-
firms that the x-ray/rinse function is on.
