8
SPECIFICATIONS
Speaker
Computer Optimized Infinite Baffle Enclosure
Speaker Frequency Response: 80Hz –15KHz
Speaker Compliment: 2 x 5inch proprietary NEO-POWER, extended-range drivers
Speaker Sensitivity: 95dB/W/M
Internal Speaker Impedance: 4 Ohms
Dimensions (HxWxD): 8.2x12x11.6inch
Weight: 15 Lbs
Amplifier
100watt Solid State class AB amplifier with soft clip feature
Signal to Noise Ratio
Better than 95 dB
Impedance
High Input: >4MΩ/22pF
Low Input: >100KΩ/22pF
Pre Amp Out: < 2KΩ
Bal. Line Out: <200Ω
Levels
High Input: 10mV-2.5V
Low Input: 20mV-5V
Pre Amp Out: 1.2V
FX send: 250mV
Bal. Line Out: Typical 600mV
Protection Circuits
1. AC line filter.
2. Slow-blow Fuse: 2.5A / 250V.
3. Smart Thermal Protection: auto turn down the output power to about 50% when the heat
sink temperature over 65º C.
4. Loudspeaker Short-Circuit Protection.
5. DC Output Protection.
Included Parts
6 ft AC Power Cord
