1 - Viewing screen collimation port 9 - Shutter trigger
2 - gate rear pressure plate 10 - Magazine release lever
3 - Film pulldown claw
4 - Take-up sprocket door
5 - Feed sprocket door
6 - Feed sprocket
7 - Take-up sprocket
8 - Magazine locking mechanism
1 2 3 4 5 6 7 9 10
8
1 - Magazine release lever
2 - Lightmeter dome
3 - Backlight LCD display
4 - Batteries compartment
5 - LED camera and timecode status indicator
6 - Control panel
7 - Camera run switch
8 - Video assist port
1 2 3 4 5 6 7 8
