a malfunction in the electrical system
and the boot lid cannot be unlocked,
the boot lid can be opened by
performing the emergency procedure
(refer to “When the boot lid cannot be
opened” paragraph in this chapter).
CLOSING
49) 50)
Use both hands to push the boot lid
down until the lock snaps shut. Do not
slam it.
Pull up on the boot lid to make sure it is
secure.
WHEN BOOT LID
CANNOT BE OPENED
If the battery is dead, the boot cannot
be unlocked and opened. In this case,
the boot can be unlocked by taking
care of the dead battery situation.
If the boot cannot be unlocked even if
the dead battery situation has been
resolved, the electrical system may
have a malfunction.
Proceed as follows:
close the convertible top and remove
the windblocker fig. 31;
remove the fasteners on the right
side of the vehicle fig. 32;
partially peel back the cover on the
right side of the vehicle fig. 33;
turn and loosen the cap screws until
the screws start to spin free fig. 34;
pull out the cap and open the boot
lid fig. 35. After performing this
emergency measure, contact an Abarth
Dealership as soon as possible.
31
08080100-125-002AB
32
08080100-121-004AB
33
08080100-122-001AB
34
08080100-999-400AB
39
