CONVERTIBLE TOP
(SOFT TOP)
LOWERING THE
CONVERTIBLE TOP
IMPORTANT Do not sit on the folded
convertible top. Otherwise, the
convertible top could be damaged or
you may fall off and be injured.
Proceed as follows:
make sure the parking brake is
applied. If the engine is running, turn it
off;
make sure there are no objects
which have been placed in the area
where the convertible top is to be
retracted;
with the lock release button 1
fig. 40 depressed forward (red mark
2 visible), pull back the top latch lever 3
fig.41tounlockit;
remove the striker 4 from the anchor
5 fig. 42;
IMPORTANT If the power windows do
not go down automatically, fully open
the windows.
standing outside of the vehicle, hold
the convertible top along the front edge
6 fig. 43 and pull it toward the vehicle
rear;
40
04110102-L36-006AB
41
04110102-L21-001AB
42
04110102-L22-002AB
42
GETTING TO KNOW YOUR VEHICLE
