10
WARNING
1) Using the levers incorrectly (levers
pushed towards the dashboard) could
break them.
EXTERNAL LIGHTS
9 AB0A0484
10 AB0A0485
DAYTIME RUNNING
LIGHTS (DRL)
2) 3)
For cars without AUTO function: With
the ignition key turned to MAR and
the ring turned to position O fig.9 or
fig.10 (for versions/markets, where
provided) the daytime running lights
are automatically activated; the other
lights and interior lighting remain off.
For cars with AUTO function:
automatic lighting with the ring turned
to AUTO.
DIPPED BEAM
HEADLIGHTS/SIDE
LIGHTS
With the ignition key in the MAR
position and ring in position
fig.9
or fig.10 (for versions/markets, where
provided). The daytime running lights
are switched off and the side lights
and dipped headlights are switched
on.
The warning light switches on in
the instrument panel.
With the ring in the AUTO position,
the side lights and the dipped
beam headlights are switched on
automatically.
MAIN BEAM
HEADLIGHTS
With ring in position
, push the
stalk forward toward the dashboard
(stable position). The warning light
switches on.
For cars with the AUTO function: with
the ring in the AUTO position and the
dipped beam headlights on, push the
stalk forwards toward the dashboard.
The main beam headlights are
switched off by pulling the stalk
towards the steering wheel.
FLASHING THE
HEADLIGHTS
Pull the stalk toward the steering
wheel and release it.
P
ARKING LIGHTS
These lights can be turned on with the
ignition switch in the STOP position or
with the key removed, by moving the
left stalk ring first to the O position (or
the AUTO position if the vehicle does
not have a dusk sensor) and then to
position
.
The
warning light switches on
in the instrument panel. Repeat the
same operation to switch them off.
