7. Technical data
7. Technical data
Measurement
Measurement range 0 – 1000 μF
Accuracy ± 1.0 %
Resolution 0.01 μF
Maximum load 2000 μF
Test voltage 1.1 – 1.4 VAC pk-pk, 40 – 160 Hz
Internal temperature accuracy ±2.0 °C from -10 °C to +50 °C (maximum)
Dimensions and weights
Complete enclosure dimensions 500 x 420 x 230 mm
Total weight 7.9 kg
CB-2000 dimensions 270 x 190 x 60 mm
Weight, cables and clip-on transformer excluded 2.4 kg
Clip-on transformer opening (Ø) 100 mm
Clip-on transformer cable length 2.0 m
Clip-on transformer extension cable length 4.0 m
Voltage supply cable length 2.0 m
Voltage supply extension cable length 4.0 m
Environment data
Operating temperature -10 °C to +50 °C
Storage temperature -30 °C to +70 °C
Climatic conditions IP 51
Electrical data
Rechargeable battery pack voltage 12 V
Rechargeable battery pack capacity 2000 mAh
Operating time > 8 hours with fully charged battery pack
Power adapter input 100 – 240 VAC 50/60 Hz
Power adapter output 24 VDC, 1.25 A
Battery pack charging time 3 hours with fully discharged batteries
Test voltage output, fuse protection 3 A, 250 V fast fuse
