Wiring with the logic relay
100
1SVC 440 795 M0100
In the circuit diagram above, I1 enables both analog value
comparators. If a value goes below the set value, A1 switches
output Q1. If another value exceeds the set value, A2
deactivates output Q1. A3 switches marker M1 on and off.
Table 10: Parameter display and parameter set for analog value
comparator:
A1 EQ +
I1 +0 Æ
F1 +0
I2 +0 æ
F2 +0
OS +0
HY +0
A1 Analog value comparator function relay 1
EQ Equal mode
The function relay has the following modes:
•
LT: less than
• LE: less than/equal to
•
EQ: equal to
• GE: greater than/equal to
• GT:greater than
+ + appears in the PARAMETER menu.
- does not appear in the PARAMETER menu
I1 Comparison value 1 (positive value I7, I8, I11, I12,
actual value T1 to T16, C1 to C16)
F1 Gain factor for I1 (I1 = F1 × actual value at I1); F1 =
positive value from 0 to 9999
I2 Comparison value 2 (positive value I7, I8, I11, I12,
actual value T1 to T16, C1 to C16)
F2 Gain factor for I2 (I2 = F2 × actual value at I2); F2 =
positive value from 0 to 9999
OS Offset for the value of I1 (I1 = OS + actual value at
I1); OS = positive value from 0 to 9999
HY Switching hysteresis for value I2
Value HY applies both to positive and negative
hysteresis.
•
I2 = Actual value at I2 + HY;
• I2 = Actual value at I2 - HY;
•
HY = Positive value from 0 to 9999
h
Work normally with analog inputs and setpoints as the
parameters for the analog value comparator.
