ABB CL-LMR 18DC1 Series User Manual

Wiring with the logic relay
170
1SVC 440 795 M0100
Rule 2
ON: Month
OFF: Month
Rule 3
ON: Year
OFF: Year
Rule 4
ON: Day/month
OFF: Day/month
Rule 5
ON: Month/year
OFF: Month/year
Rule 6
ON: Day/month/year
OFF: Day/month/year
Rule 7
Two-channel
Channel A ON: Day/month
Channel B OFF: Day/month
Y1 A +
ON --.XX.--
OFF --.XX.--
Y1 A +
ON --.--.XX
OFF --.--.XX
Y1 A +
ON XX.XX.--
OFF XX.XX.--
Y1 A +
ON --.XX.XX
OFF --.XX.XX
Y1 A +
ON XX.XX.XX
OFF XX.XX.XX
Y1 A +
ON XX.XX.--
OFF --.--.--
Y1 B +
ON --.--.--
OFF XX.XX.--
