TYPE CV FREQUENCY
COMPENSATED VOLTAGE RELAY
Figure 10: Typical Time Curves of the Type CV-25 Short Time Overvoltage Relay
Sub 2 406C882
0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190 200 210 220 230 240 250
Percent Tap Value Voltage
