7
7.3 Current Consumption of EBN853
Table 3
7.4 Current consumption of EBN861
Table 4
7.5 Fuses
1)
The 35 A fuse and the thermal safety cutout (16 A) are included in the scope of delivery. They ensure
safe operation for the special swiching conditions of power electronics EBN861. Note that the cable
cross-sectional area between the fuse and the electronics must be at least 2.5 mm
2
.
I
max
115 V I
max
230 V I
pos.
RHD250-10 1.8 A 0.9 A
each approx.
40 .. 50% of Imax
RHD500-10 2.2 A 1.1 A
RHD800-10 3.4 A 1.7 A
RHD1250-12 6.0 A 3.0 A
RHD2500-25 4.8 A 2.4 A
RHD4000-40 4.0 A 2.0 A
RHD8000-80 4.0 A 2.0 A
RSD10-5,0 3.4 A 1.7 A
RSD10-10,0 3.8 A 1.9 A
RSD20-5,0 4.8 A 2.4 A
RSD20-7,5 3.8 A 1.9 A
RSD50-3,0 4.0 A 2.0 A
RSD100-1,5 4.4 A 2.2 A
RSD200-0,7 5.0 A 2.5 A
I
max
230 V I
pos.
RHD2500-10 5.3
each approx.
40 ... 50% of Imax
RHD4000-10 10.0
RHD8000-12 9.0
RHD16000-30 10.2
RSD50-10,0 6.4
RSD100-10,0 12.5
RSD200-5,5 13.0
Electronic
unit
Fuse type Mounting site U = 115 V
U = 230 V
1)
EAN823 External fuse external 16 A, slow
Mains fuse in connection chamber 6.3 A, slow 3.15 A, slow
Analogue setpoint input in connection chamber 40 mA; fast
Anti condensation heater in connection chamber 2 A; slow
EBN853 External fuse external 16 A, slow
Mains fuse in connection chamber 12.5 A, slow 10 A, slow
Analogue setpoint input in connection chamber 40 mA; fast
Brake fuse power board 0.315 A, medium time-lag
Intermediate circuit fuse power board 10 A, super-quick
Anti condensation heater in connection chamber 2 A; slow
EBN861
External fuses
1)
external
--
35 A fuse
16 A thermal
safety cutout
Brake fuse on board (power section)
--
0.315 A,
medium time-
lag
Intermediate circuit fuse power board
--
15 A, medium
time-lag
Table 5
