Technical data 33
Relay outputs (XRO1:11…13, XRO2:21…23)
•
Connector pitch 5 mm, wire size max. 2.5 mm
2
• Torque: 0.5 N·m
• Max. contact voltage: 120 V DC, 250 V AC
• Max. contact current/power:
5 A, 24 V DC; 0.4 A, 120 V DC; 1250 VA, 250 V AC
• Max. continuous current: 2 A rms
• Minimum current: 10 mA, 24 V DC
• Contact material: AgNi
• Outputs isolated from each other, the digital inputs, power
supply and ground (earth)
• Contact protection: Varistor (250 V)
• Insulation strength: > 4kV
Power supply
•
+3.3 V and 24 V (supplied by the drive control unit or the FEA-
03 extension adapter module)
• Max. power consumption: 100 mA at 3.3 V, 25 mA at 24 V
General
•
Complies with standards EN 61800-3, EN 61800-5-1, UL508C
• cULus listed
• Printed circuit board conformal coated
