Operation Manual / TPS44-F.. - TPS61-F..
Operation
4
Noise emissions
4.1
Page 44
April 2015 HZTL2412_EN Revision E
Suggestion for noise insulation of the bellows
01 Compressor casing
02
Bellows
03 Charge air duct / scavenging air line
04 Insulation pads
05 Insulation mat (at least 15 mm)
06 Sheet metal cover
