Operation Manual / TPS
44-F.. - TPS61-F..
Disassembly and assembly
8
Disassembling and assembling
turbocharger
8.3
Page 96
© Copyright 2016 AB
B. All r
ights reserved.
August
20
17
HZTL24
12_EN
Revision
F
Removing the insulation
τ
Loosen
and
remove
the
screws
for
the
insulation
plates (1,
2).
τ
If
provided:
Remove
the
insulation
plates
(1,
2).
τ
Remove
the
remaining
screws
for
the
insulation
(3).
τ
Remove
the
insulation
(3).
If provided
97
99
