Operation Manual / TPL65-A32 / -A33 / -A36 + TPL69-A32 / -A33
12 Spare parts / 12.2 View of the turbocharger with part numbers
© Copyright 2018 . All rights reserved. HZTL2498_EN Revision C April 2018
Part number Description
– Cartridge group
42012 (in spare part set) O-ring
51001 Gas inlet casing
51012 (if provided) Segment
56001 Nozzle ring
61001 Gas outlet casing
61036 Stud
61037 (in customer spare part
set)
Hexagon nut
61043 (in customer spare part
set)
Verbus Ripp® Washer
61044 (in customer spare part
set)
Hexagon-head screw
61050 (only TPL65-A32 / -A33) Spiral gasket
61056 (in customer spare part
set)
Hexagon-head screw
61057 (in customer spare part
set)
Verbus Ripp® Washer
61058 (in customer spare part
set)
Verbus Ripp® Washer
61059 (in customer spare part
set)
Hexagon-head screw
63000 Turbine diffuser
68000 Foot
72000 Compressor casing
72018 Washer
72027 Hexagon nut
72029 Stud
77000 Wall insert
77005 (in customer spare part
set)
O-ring
79000 Diffuser
81000 Filter silencer
82000 Radial air suction branch
82000 Axial air suction branch
Page 117 / 118
