Operation Manual / TPL65-A32 / -A33 / -A36 + TPL69-A32 / -A33
8 Disassembly and assembly / 8.9 Table of tightening torques
© Copyright 2018 . All rights reserved. HZTL2498_EN Revision C April 2018
Tightening torques [Nm]
Position Part number TPL65-A32 / -A33 / -
A36
TPL69-A32 / -A33
01 82005 M16x1.5
45
M16x1.5
45
04 72027
with washer
M14
95
M16
125
05 72029 M14
30
M16
30
06 61044
61059
61071 (TPL69-A32/33)
M14
160
- -
M16
260
61056 M14
150
M16
260
07 61036 M12
80
M16
105
10 61037 M14
75
M16
105
11 61090 M14
5
M16
10
14 86505 M18x1.5
150
M18x1.5
150
103 72002 M10
50
M12
80
Page 97 / 118
