Operation Manual /
TPS44
-
F..
-
TPS6
1
-
F..
Operation
4
Noise emissions
4.1
Page 44
© Copyright
2016 ABB.
All rig
hts reserved.
September 2016
HZTL2412_EN
Revisi
on F
Suggestion for noise insulation of the bellows
01
Compress
or casi
ng
04
Insulatio
n pads
02
Bello
ws
05
Insulatio
n mat (at
least 15
mm)
03
Charge air
duct / s
cavengi
ng
air lin
e
06
Sheet meta
l cover
45
47
