Operation Manual / TPS44-F.. - TPS61-F..
Shutting down the turbocharger
Page 116
© Copyright 2016 ABB. All rights reserved.
September 2016 HZTL2412_EN Revision F
Close the opening in the turbine casing using the cover plate (A).
Fasten the cover plate on the turbine casing (51000) using the fas-
tening strips (51002), Verbus Ripp® Verbusripp washers (51003) and
nuts (51007) and screw it down securely on the support.
Thoroughly clean the fastening strips (51002) before fitting them. Apply
high-temperature grease to the stud threads (51006).
