Operation Manual / A150-M56/66/57/67 - A155-M..
14 Fitting the cleaning nozzles with multi-inlet turbine casings / 
© Copyright 2021 ABB. All rights reserved. HZTL4032_EN Rev.Q January 2021
14 Fitting the cleaning nozzles with multi-
inlet turbine casings
Fig.127: Fit the cleaning nozzles
1. The designation(P . ) on the turbine casing must correspond with the designation(P . )
on the cleaning nozzle.
2. The edges for the defined installation position in the turbine casing and at the cleaning
nozzle must correspond.
Page 164 / 194
