Operation Manual / 1 Introduction
Page 5 /
© Copyright 2016 ABB. All rights reserved.
The following pictograms can occur in this document. These point out actions that must be
taken in accordance with the meaning of the relevant pictogram.
Tighten with specified torque
Affix
Tighten over specified tightening
angle
Hand-tight, tighten without tools
Note
Oil
Visually inspect
Apply screw locking paste (e.g.
Loctite)
Please note text for numbered
work step.
Apply high-temperature grease
Apply other paste in accordance
with specifications
Dispose of in an environmentally
compatible, professional way and
in compliance with locally applica-
ble regulations.
Oil free, grease free and dry
Table 1: Definition of pictograms
