15.4.1 Process Supply Voltage
CAUTION!
The process supply voltage must be included in the earthing concept (e. g.
earthing of the minus pole).
15.4.2 Inputs/Outputs
Fig. 25: Example for connection input DIx
Fig. 26: Example for connection input AIx
Examples
DA501
Connection > Inputs/Outputs
