ABB REF 545 User Manual

1MRS755312
REF 541/543/545
REM 543/545
RET 541/543/545
27
Connectivity Packages
User’s Guide
TOL3Dev DEV PTTR 48 Three-phase thermal overload
protection for devices
UE6High - PDIR 67 Three-phase underexcitation
protection, high-set stage
UE6High - PDUP 67 Directional underpower of three-
phase underexcitation protection,
high-set stage
UE6High - RBRF 67 Circuit breaker failure of three-
phase underexcitation protection,
high-set stage
UE6Low UE PDIS 66 Three-phase underexcitation
protection, low-set stage
UI6High - PDIS 111 Three-phase underimpedance
protection, high-set stage
UI6High - RBRF 111 Circuit breaker failure of three-
phase underimpedance protection,
high-set stage
UI6Low UI PDIS 110 Three-phase underimpedance
protection, low-set stage
UI6Low UI RBRF 110 Circuit breaker failure of three-
phase underimpedance protection,
low-set stage
UPOW6St1 PH PDIR 95 Three-phase underpower or
reverse power, stage 1
UPOW6St1 PH PDUP 95 Directional underpower
UPOW6St1 PH RBRF 95 Circuit breaker failure of three-
phase underpower or reverse
power, stage 1
UPOW6St2 PH PDIR 96 Three-phase underpower or
reverse power, stage 2
UPOW6St2 PH PDUP 96 Directional underpower
UPOW6St2 PH RBRF 96 Circuit breaker failure of three-
phase underpower or reverse
power, stage 2
UPOW6St3 PH PDIR 97 Three-phase underpower or
reverse power, stage 3
UPOW6St3 PH PDUP 97 Directional underpower
UPOW6St3 PH RBRF 97 Circuit breaker failure of three-
phase underpower or reverse
power, stage 3
UV3High PH PTUV 65 Three-phase undervoltage
protection, high-set stage
UV3Low PH PTUV 64 Three-phase undervoltage
protection, low-set stage
VOC6High - PVOC 107 Voltage controlled/dependent time
overcurrent
Table 5.-1 LN prefixes for RED500 (Continued)
Function Block
Name
IEC 61850 Logical Node Name Description
Logical Node Prefix Logical Node Class
Logical Node
Instance
(Channel Number)
