28
1MRS755312
Connectivity Packages
User’s Guide
REF 541/543/545
REM 543/545
RET 541/543/545
VOC6High - RBRF 107 Circuit breaker failure of voltage
controlled/dependant time
overcurrent
VOC6Low PH PVOC 91 Voltage dependent overcurrent
protection, low-set stage (51V)
VOC6Low PH RBRF 91 Circuit breaker failure of voltage
dependent overcurrent protection,
low-set stage
NOC3LowB PH PTOC 53 Three-phase non-directional
overcurrent function, low-set stage
NOC3LowB PH RBRF 53 Circuit breaker failure protection of
three-phase non-directional
overcurrent function, low-set stage
REF4A REF PDIF 101 Stabilized restricted earth-fault
protection, high voltage side
REF4A REF RBRF 101 Circuit breaker failure protection of
stabilized restricted earth-fault
protection, high voltage side
REF4B REF PDIF 119 Stabilized restricted earth-fault
protection, low voltage side
REF4B REF RBRF 119 Circuit breaker failure protection of
stabilized restricted earth-fault
protection, low voltage side
Diff6T GEN PDIF 106 Stabilized three-phase differential
protection for transformers
Diff6T GEN RBRF 106 Circuit breaker failure protection of
stabilized three-phase differential
protection for transformers
Control
CO3DC1 DCO3 CILO 139 Three state disconnector 1,
interlocking
CO3DC1 DCO3 CSWI 139 Three state disconnector 1, switch
control
CO3DC1 DCO3 XSWI 139 Three state disconnector 1,
disconnector information
CO3DC1_1 ESW3 CILO 139 Three state disconnector 1,
interlocking
CO3DC1_1 ESW3 CSWI 139 Three state disconnector 1, switch
control
CO3DC1_1 ESW3 XSWI 139 Three state disconnector 1,
disconnector information
CO3DC2 DCO3 CILO 140 Three state disconnector 2,
interlocking
CO3DC2 DCO3 CSWI 140 Three state disconnector 2, switch
control
CO3DC2 DCO3 XSWI 140 Three state disconnector 2,
disconnector information
Table 5.-1 LN prefixes for RED500 (Continued)
Function Block
Name
IEC 61850 Logical Node Name Description
Logical Node Prefix Logical Node Class
Logical Node
Instance
(Channel Number)
