1MRS755312
REF 541/543/545
REM 543/545
RET 541/543/545
29
Connectivity Packages
User’s Guide
CO3DC2_1 ESW3 CILO 140 Three state disconnector 1,
interlocking
CO3DC2_1 ESW3 CSWI 140 Three state disconnector 2, switch
control
CO3DC2_1 ESW3 XSWI 140 Three state disconnector 2,
disconnector information
COCB1 CB CILO 120 Circuit breaker 1, interlocking
COCB1 CB CSWI 120 Circuit breaker 1, switch control
COCB1 CB XCBR 120 Circuit breaker 1, circuit breaker
information
COCB2 CB CILO 121 Circuit breaker 2, interlocking
COCB2 CB CSWI 121 Circuit breaker 2, switch control
COCB2 CB XCBR 121 Circuit breaker 2, circuit breaker
information
CODC1 DCO CILO 122 Disconnector 1, interlocking
CODC1 DCO CSWI 122 Disconnector 1, switch control
CODC1 DCO XSWI 122 Disconnector 1, disconnector
information
CODC2 DCO CILO 123 Disconnector 2, interlocking
CODC2 DCO CSWI 123 Disconnector 2, switch control
CODC2 DCO XSWI 123 Disconnector 2, disconnector
information
CODC3 DCO CILO 124 Disconnector 3, interlocking
CODC3 DCO CSWI 124 Disconnector 3, switch control
CODC3 DCO XSWI 124 Disconnector 3, disconnector
information
CODC4 DCO CILO 125 Disconnector 3, interlocking
CODC4 DCO CSWI 125 Disconnector 3, switch control
CODC4 DCO XSWI 125 Disconnector 3, disconnector
information
CODC5 DCO CILO 126 Disconnector 5, interlocking
CODC5 DCO CSWI 126 Disconnector 5, switch control
CODC5 DCO XSWI 126 Disconnector 5, disconnector
information
COIND1 ESW CSWI 127 Switch controller
COIND1 ESW XSWI 127 Object indication 1, non-
controllable
COIND2 ESW CSWI 128 Switch controller
COIND2 ESW XSWI 128 Object indication 2, non-
controllable
COIND3 ESW CSWI 129 Switch controller
COIND3 ESW XSWI 129 Object indication 3, non-
controllable
COIND4 ESW CSWI 130 Switch controller
Table 5.-1 LN prefixes for RED500 (Continued)
Function Block
Name
IEC 61850 Logical Node Name Description
Logical Node Prefix Logical Node Class
Logical Node
Instance
(Channel Number)
