30
1MRS755312
Connectivity Packages
User’s Guide
REF 541/543/545
REM 543/545
RET 541/543/545
COIND4 ESW XSWI 130 Object indication 4, non-
controllable
COIND5 ESW CSWI 131 Switch controller
COIND5 ESW XSWI 131 Object indication 5, non-
controllable
COIND6 ESW CSWI 132 Switch controller
COIND6 ESW XSWI 132 Object indication 6, non-
controllable
COIND7 ESW CSWI 133 Switch controller
COIND7 ESW XSWI 133 Object indication 7, non-
controllable
COIND8 ESW CSWI 134 Switch controller
COIND8 ESW XSWI 134 Object indication 8, non-
controllable
COPFC PFC ARCO 143 Power factor controller
Condition Monitoring
CMBWEAR1 CBEW GGIO 187 Circuit breaker electric wear 1
CMBWEAR2 CBEW GGIO 188 Circuit breaker electric wear 2
CMCU3 SCC GGIO 181 Supervision function of the
energizing current input circuit
CMGAS1 - SIMG 186 Gas density monitoring
CMGAS3 - SIMG 194 Gas density monitoring of three
poles
CMSHED CHED GGIO 189 Scheduled maintenance
CMSPRC1 SPRC GGIO 190 Spring charging control 1
CMTCS1 TCS GGIO 191 Trip circuit supervision 1
CMTCS2 TCS GGIO 192 Trip circuit supervision 2
CMTIME1 T GGIO 184 Operate time counter 1 for the used
operate time (motors)
CMTIME2 T GGIO 185 Operate time counter 2 for the used
operate time (motors)
CMTRAV1 TRT GGIO 193 Breaker travel time 1 supervision
CMVO3 SVC GGIO 182 Supervision of the energizing
voltage input circuit
Measurement
MEAI1 GM GGIO 213 General measurement 1
MEAI2 GM GGIO 214 General measurement 2
MEAI3 GM GGIO 215 General measurement 3
MEAI4 GM GGIO 216 General measurement 4
MEAI5 GM GGIO 217 General measurement 5
MEAI6 GM GGIO 218 General measurement 6
MEAI7 GM GGIO 219 General measurement 7
MEAI8 GM GGIO 220 General measurement 8
MECU1A I MMXU 201 Current measurement A
Table 5.-1 LN prefixes for RED500 (Continued)
Function Block
Name
IEC 61850 Logical Node Name Description
Logical Node Prefix Logical Node Class
Logical Node
Instance
(Channel Number)
