Technical Data ENG 36
Max. line length: 100 m
Max. line length between the
data outputs:
From device to
device, max. 30 cm;
total length max. 2 m
Max. total cable length between
the RJ 12 connectors:
From device to
device, max. 30 cm;
total length max. 2 m
Type of protection: IP 20
Ambient temerature range: 0 – +45 °C
(see Fig. 3)
Use the prefabricated RJ 12 cable (included in
the scope of supply of the power module 6584-
xxx) to connect the devices.
