ABB Transformer Protection Unit 2000R
5-2
Interfacing with Relay
Man-Machine Interface Menus
Below is an outline of the menus available through the man-machine interface.
Figure 5-2. Man-Machine Interface Menus
METER MENU
Load
Demand
Max/Min Demand
SHOW SETTINGS MENU
Prim Settings
Alt1 Settings
Alt2 Settings
Configuration
Alarm Settings
Clock
Communications
CHANGE SETTINGS MENU
Prim Settings+
Alt1 Settings+
Alt2 Settings+
Configuration+
Counter Settings+
Alarm Settings+
Clock+
Communications+
RECORDS MENU
Diff. Fault Record
Through Fault Record
Operations Record
Operations Summary
SETTING MENU
Show Settings
Change Settings
Unit Information
+ Password protected
MAIN MENU
Meter
Settings
Records
Operations
TEST MENU
Self Test
Contact Inputs
Output Contacts+
UNIT INFORMATION
CAT 588R0411-6111
SERIAL # : 951280
CPU ROM : V2.23
DSP ROM : V2.10
FP ROM : V1.10
COMM ROM : V2.10
Restraint Record
Differential
Test
Reset Energy Meters
OPERATIONS MENU
Trip Breaker
Force Phy. Input
Force Phy. Output
Set/Clear ULO
Force Logical Input
