ABB VD4/R User Manual

7
Pole centre distance Technical documentation
U [kV] In [A] Isc [kA] Description 230 mm 300 mm Dimensions Electric diagram
12 630 12.5 VD4/R 12.06.12
16 VD4/R 12.06.16
20 VD4/R 12.06.20
25 VD4/R 12.06.25
800 16 VD4/R 12.08.16
20 VD4/R 12.08.20
25 VD4/R 12.08.25
1250 16 VD4/R 12.12.16
20 VD4/R 12.12.20
25 VD4/R 12.12.25
17.5 630 12.5 VD4/R 17.06.12
16 VD4/R 17.06.16
20 VD4/R 17.06.20
25 VD4/R 17.06.25
800 16 VD4/R 17.08.16
20 VD4/R 17.08.20
25 VD4/R 17.08.25
1250 16 VD4/R 17.12.16
20 VD4/R 17.12.20
25 VD4/R 17.12.25
24 630 12.5 VD4/R 24.06.12
16 VD4/R 24.06.16
20 VD4/R 24.06.20
800 16 VD4/R 24.08.16
20 VD4/R 24.08.20
1250 16 VD4/R 24.12.16
20 VD4/R 24.12.20
1VCD000100
(230 mm);
1VCD000101
(300 mm)
1VCD000100
(230 mm);
1VCD000101
(300 mm)
1VCD400097
1VCD400097
1VCD000100
(230 mm);
1VCD000101
(300 mm)
1VCD400097
5.3.3. Types available of fixed circuit-breakers VD4/R 12-17-24 (right lateral operating mechanism)
