ABB VD4 Series Instruction Manual

ABB Calor Emag Mittelspannung GmbH ABB Sace T.M.S. S.p.A
Oberhausener Strasse 33 Petzower Strasse 8 Via Friuli, 4
D-40472 Ratingen D-14542 Glindow I-24044 Dalmine
Phone: +49(0)21 02/12-12 30, Fax: +49(0)21 02/12-19 16 Phone: +39 035/395111, Fax: +39 035/395874
E-Mail: calor.info@de.abb.com E-mail: sacetms.tipm@it.abb.com
Internet: http://www.abb.de/calor Internet: http://www.abb.com
Instruction manual no. GCEA 67 0434 P0102 Printed in Germany (07.00-1000-PPI) We reserve the right to make changes in the course of technical development.

ABB VD4 Series Specifications

General

Operating mechanism	Spring-operated mechanism
Installation	Fixed or withdrawable
Rated frequency	50/60 Hz
Poles	3
Rated current	Up to 4000 A
Standards	IEC 62271-100
Insulation	Vacuum
Application	Medium voltage
Control voltage	24-240 V AC/DC
Weight	Depending on the specific model
