49
10-90342 - BROOM ARMS AND HARDWARE: HYD LIFT
ITEM PART # DESCRIPTION
1 10-20100 USS 1/2 FLAT WASHER, ZINC
2 10-20125 PIN:3/8" SQ WIRELOCK:3.75 OAL
3 10-20133 3/8" SPLIT LOCKWASHER ZNC
4 10-20138 1/2-13 HEX FIN NUT GR 5 ZNC
5 10-20139 1/2" SPLIT LOCKWASHER ZNC
6 10-20146 CHAIN: PICK UP: 56 LINKS
7 10-20154 5/16" SNAP HOOK
8 10-20195 FLT WSHR:3/8 SAE: CL ZINC
9 10-20279 HX HD BOLT:3/8-16 1.0 ZINC GR5
10 10-30970 BRKT:LH MOUNT: BROOM
11 10-30971 BRKT:RH MOUNT: BROOM
12 10-30973 PLATE:CHAIN MNT: BROOM
13 10-40133 WLDMT: BROOM ARM:FORCE
1
5
4
13
9
3
8
10
12
11
7
2
