DELELISTE / DELLISTA / PARTS LIST
PART NO. DESCRIPTION MATERIAL SPECIFICATION Q’TY
1 Main frame
1
2 Front stabilizer Q195 D76x1.5Tx480L 1
3 Allen bolt 35# M8*1.25*95L 4
4 Adjustable foot cap PP D76*86 2
5L Front foot cap (left) PP D76*120L 1
5R Front foot cap (right) PP D76*120L 1
6 Curved washer Q235A D22xD8.5x1.5T 20
7 Spring washer 70# D15.4xD8.2x2T 14
8 Domed nut Q235A M8x1.25x15L 4
9 Allen bolt 35# M8x1.25x20L 8
10 Handlebar post
1
11 Pedal supporting tube
2
12 Movable support welding set
2
13 Bushing
D35*11L 4
14 Spacer
D19.15x(D25.6x32)xL(17+3) 8
15 Side cap PVC D25.4*31L 2
16 Bearing GCr15 #99502 2
17 Allen bolt 35# M8x1.25x100L 2
18 Nut Q235A M8*1.25*8T 2
19 Rear stabilizer Q195 D76x1.5Tx480L 1
20 Square bolt Q235A M6*1*45L 4
21L Left pedal PP 420*130*85 1
21R Right pedal PP 420*130*85 1
22 Cross screw 10# ST4x1.41x10.L 2
23A Right protective cover HIPS88 80*50*87 2
23B Left protective cover HIPS88 80*55*87 2
To Next Page
