Abilica Stream UB VIII User Manual

5
DELELISTE / DELLISTA / PARTS LIST / OSALUETTELO
PART NO. DESCRIPTION MATERIAL SPECIFICATION Q’TY
1 Main frame 1
2 Rear stabilizer Q195 D76x1.5Tx480L 1
3 Adjustable foot cap PP D76*86 2
4 Front stabilizer Q195 D76x1.5Tx480L 1
5L Front left foot cap PP5070 D76*120L 1
5R Front right foot cap PP5070 D76*120L 1
6 Domed nut Q235A M8x1.25x15L 4
7 Allen bolt 35# M8*1.25*95L 4
8 Oval side cap PP 25*50*28L 2
9 Seat supported tube 1
10 Seat PVC DD-356 1
11 Seat adjustable tube 1
12 Spring washer 70# D15.4xD8.2x2T 8
13 Curved washer Q235A D22xD8.5x1.5T 10
14 Screw 10# ST4*1.41*15L 2
15 Adaptor 9V,1.5A 1
16 Foam (HDR) NBR D20*5.5T*560L 2
17 Flat washer Q235A D25xD8.5x2T 1
18 Club knob SS41+ABS D60x32L(M8x1.25) 1
19 Side cap PP D7/8"x17L 2
20 Allen bolt 35# M8*1.25*15L 6
21 Poly belt PJ5 1118 1
22 Waved washer 65Mn D21xD16.2x0.3T 2
23 Flat washer Q235A D24xD16x1.5T 1
24 Fly wheel set 1
25 Left chain cover PS 901.8*79.5*558.3 1
26 Right chain cover PS 901.8*75*558.3 1
27 Belt wheel ZL102 D260*19 1
28 Oval protective cover ABS 1
29 Handlebar post tube 1
