appendIx
24
Model Variant
3W2214 3W2217 3W4401
Compliance IEC 61851-1 / 61439-7
Grid connection
Direct connection to residual current circuit
breaker (RCCB)
PE: Feed-through terminal block, max. 5 x 10
mm²
for two supply cables of
max. 5 x 10 mm² each
Rated voltage 230 / 400 V
Rated current 32 A, 3-phase 2 x 32 A, 3-phase
Rated frequency 50 Hz
Max. output 2 x 11 kW or 1 x 22 kW 2 x 22 kW
Charging outlet
Lockable Type 2 charg-
ing socket in acc. with
IEC62196-2, 2 pcs.
Type 2 charging socket
with shutter in acc. with
IEC62196-2; 2 pcs.
Lockable Type 2 charg-
ing socket in acc. with
IEC62196-2, 2 pcs.
Circuit-protection
devices
Type A 30 mA RCCB, and DC-RCM I
Δn d.c.
electronic DC fault current detector
≥ 6 mA
Control /
Customization
Internal RS485 and USB interfaces
(no user access)
Operating temperature -30°C to 50°C
Storage temperature -30°C to 85°C
Relative humidity 5 to 95% (no condensation)
Class of protection I
Overvoltage category III
Degree of pollution 3
Degree of protection
(housing)
IP54
Impact strength IK08
Dimensions incl.
Mounting plate
492 x 400 x 192 mm
(H x W x D)
Dimensions
w/o mounting plate
492 x 400 x 162 mm
(H x W x D)
Mounting plate dimen-
sions
477.9 x 376.4 x 32 mm
(H x W x D)
Maximum elevation ≤ 2,000 m AMSL (above mean sea level)
Weight per unit incl.
mounting plate
ca. 5.7 kg
Weight per unit
w/o mounting plate
ca. 4.7 kg
