17
ASSEMBLING SPLIT SPINDLE (EL480)
Fig. H
Handle returning spring is installed on the electrically controlled side.
Needed tool: 2.5mm Allen key
1. Assemble inside spindle (A), spring (B) and screw (C).
2. Locate cone-shaped spring (D) into outside handle follower as shown in the
figure (E) and push the outside spindle (E) against lock case.
3. Put inside spindle in its place and screw in the screw until it stops. Tighten the
screw.
Note that the screw has 20mm long thread!
Spindles must extend 20mm inside the handles. Use long split spindle when
neede.
ENGLISH
