EN
11
Motor Belt Adjustments
While each treadmill motor belt has been finely adjusted, after transport and installation
it may need to be adjusted again and also throughout the life of the treadmill.
Adjustment Steps:
1. Adjust the balance of the motor with the allen key. Turn the bolt half a turn counter
clockwise.
2. Turn the belt tightening bolts clockwise half a circle.
NOTE: Clean belt and pulley grooves regularly.
Folding Instructions
1. Lift the handles upwards and turn the locking knobs to the unlock position.
2. Then slowly fold the frame down towards the the tread belt
WARNING
Unplug the treadmill before performing maintenance.
Front Roller
Belt tightness
bolts
Motor balance
adjustment bolts
Motor
Belt
Locking Knob
Handles
To Next Page
