ABSTRACT Universal - DMX values

Abstract Universal Instruction Manual
Page 15
DMX values
Pan (Swivel on ClubRev)-Ch1 Tilt (Ch 2)
DMX Result DMX Result
0Left 0Top
128 Central 128 Central
255 Right 255 Bottom
Rotation (Ch 2 on ClubRevolution)
DMX Result
0 Stop
12 Fastest speed clockwise
112 Slowest speed clockwise
128 Stop
141 Slowest speed a.clockwise
244 Fastest speed a.clockwise
255 Stop
Colour (Ch 3) and colour / gobo
DMX Colour only Colour / Gobo
0White Blackout (Twister 4)
10 White White/open
26 Red Red/dot tunnel
43 Blue Blue/Slash
59 Green Green/Segment
75 Yellow Yellow/Triangle
91 Cyan Cyan/Tunnel
108 Orange Orange/Bubbles
124 Magenta Pink/Stars
140 Neon Green Multicolour
156 Pink Orange/Bubbles
173 UV Blue Cyan/Tunnel
189 Multicolour Yellow/Triangle
221 UV blue Blue/Slash
238 Pink Red/dot tunnel (Slow strobe on
Tw4
)
254 Neon Green Red (Fast strobe on Twister 4)
NB: Intermediate values will give mixed colours
Gobo (Ch 4) / Shutter
