16
3. Connections and functions
3.1 Power supply
ATTENTION!
Before you begin the installation, make sure that the supply voltage and the nominal
voltage of the camera match.
12 VDC, round plug, 5,5 x 2,1 mm
3.2 Installation
For installation notes please refer to the quick guide in the delivered product package.
3.3 Call factory default settings (Reset)
1. Please disconnect the camera form power
connection.
2. Press the "Reset" button on the camera and
keep it pressed.
3. Now connect the power supply to the camera
(2-pin power supply or Power over Ethernet),
and hold the "Reset" button pressed for
another 30 seconds.
3.4 SD card slot
To install the Micro SD card the cover and the dome bubble need to be removed first. The Micro-
SD card slot is located on the back of the camera.
Max. SD card size: 128 GByte
Before usage of micro SD card the card must be formatted.
Reset
Micro SD
Card
