16
3. Connections and functions
3.1 Power supply
ATTENTION!
Before you begin the installation, make sure that the supply voltage and the nominal
voltage of the camera match.
12 VDC, round plug, 5,5 x 2,1 mm
3.2 Call factory default settings (Reset)
1. Please disconnect the camera form power
connection.
2. Press the "Reset" button on the camera
and keep it pressed.
3. Now connect the power supply to the
camera (2-pin power supply or Power over
Ethernet), and hold the "Reset" button
pressed for another 30 seconds.
3.3 SD card slot
To install the Micro SD card the cover and the
dome bubble need to be removed first. Der
Micro-SD Karteneinschub befindet sich unter
dem Kamerasmodul
Max. SD card size: 128 GByte
Before usage of micro SD card the card must be formatted.
