20
4. For cable routing, drill a suitable hole in
the middle of the floor panel in the
ground, or use the optional box hole on
the floor panel for side cable routing (in
this case, the cable must be routed
sideways before installing the floor panel).
5. Then attach the camera head with fixing
cap and fix the fixing screw lightly.
3.3 Alignment of camera
A: Pan
B: Tilt
C: Rotation
Tighten the fixing screw to the desired
orientation of the camera head.
3.4 Reset to factory default
The Reset Settings button is located on the
side of the camera head behind a cover
plate.
1. Disconnect the camera.
2. Press and hold the "Reset" button on the
camera.
3. Now connect the power supply to the
camera (via 2-pin power supply or Power-
over-Ethernet) and press the "Reset" button
for another 30 seconds.
B
C
