Abus ITAC10300 - Page 2

Internet
Powerline_Instruction_Schematic V 1.0
Connection indicator / Displays connection strength
Network indicator / Displays network status
Encoding indicator / Displays security status
PoE indicator / Displays PoE status
Powerline PoE Adapter - ITAC10310
Connection indicator / Displays connection and security status
Network indicator / Indication when network is active
Power indicator / Indication when device is in operation
Powerline Adapter - ITAC10300
For details, please refer to the operating instructions,
which are available online under the product number
www.abus.com
Note, that the schematic shows an exemplary
installation.
ABUS
plug-and-play connection
ITAC10300
ITAC10300
ITAC10310
ITAC10310
electrical line
