Abus PPIC35520 - Door Station Rear;Side View Components; Adjustable Lens and Reset Button; MicroSD Card Slot; Interface Connections

Justierbares Objektiv
Adjustable lens
C2/C1: Anschluss für externe
Türklingel (Potentialfreies Relais,
Max. Input: 2A/24V AC/DC)
C2/C1: Connection for external
door bell (Potential-free relay,
max. Input: 2A/24V AC/DC)
MicroSD Kartenslot
(max. 128 GB)
MicroSD card slot
(max. 128 GB)
Reset Taste
Reset button
TD-/TD+/RD-/RD+: Anschluss
für LAN-Schnittstelle
TD-/TD+/RD-/RD+: Connection
for LAN-interface
V-/V+:
Aschluss für
Spannungsversorgung
(24-36V AC, 12-48V DC)
V-/V+: Connection for
Power Supply (24-36V AC,
12-48V DC)
B2/B1: Anschluss für
z.B. Türöner (Poten-
tialfreies Relais, Max.
Input: 2A/24V AC/DC)
B2/B1: Connection
for f.e. door opener
(Potential-free relay,
max. Input: 2A/24V
AC/DC
