INSTALLATION
Consider the following factors when positioning the solar panel.
These factors can aect the solar panel’s eciency:
• Mount the solar panel in a place that receives a steady level of sunlight all year round.
For a charged camera battery, usually only a few hours of direct sunlight per day are enough.
• Weather conditions, seasonal changes and geographical location will aect the solar panel‘s
power generation.
• Dirt or debris on the panel can adversely aect the absorption of sunlight.
Mark the position of the required 3 drill holes at the desired
location, using the drilling template or the wall bracket and
a pencil or other utensil to do so. You can unscrew the bracket
to do this. When choosing a location, also consider the
maximum length of the solar panel cable.
Drill the holes and insert the screw anchors provided.
Secure the wall bracket with the enclosed screws.
1
Turn the ball joint of the bracket with the thread into the
corresponding opening on the back of the solar panel.
Tighten the enclosed union nut so that the ball joint and
solar panel are rmly connected.
2
Finely adjust the solar panel so that it receives as much
sunlight as possible throughout the day. We recommend
tilting the solar panel at an angle of approx. 30° to an
imaginary horizontal line. Now tighten the ball joint with
the wing screw.
30°
3
4
On the back of your WiFi Battery Cam, completely remove the
original red cover by pulling out the rubber anchor of the red
cover completely.
1.
