23
English
6.2 Cleaning
Wipe the product with a clean, dry cloth. If the device is very dirty, you can moisten the cloth with
lukewarm water.
Ensure that no liquids can get into the device.
Do not use any chemical cleaners, since they could damage the housing surface or the
screen (discolorations).
7. Disposal
Important: The EU Directive 2002/96/EC regulates the proper return, treatment and
recycling of used electronic devices. This symbol means that in the interest of
environmental protection the device must be disposed of separately from household or
industrial waste at the end of its service life in accordance with applicable local legal
guidelines. Disposing of used devices can be done at official recycling centers in your
country. Obey local regulations when disposing of material. Further details on returns
(also for non-European countries) can be obtained at your local authority. Separate
collection and recycling saves natural resources and ensures that all the provisions for
protecting health and environment are observed when recycling the product.
8. Technical Data
Model number TVCC91700
Image sensor 1/3” CMOS
Camera type Universal Analog Dome IR 720 TVL
Resolution 720 TVL
Pixels (effective) 1280 (H) x 960 (V)
Lens 2.8-12mm @ F1.4
Horizontal angle of view 80° - 27.2°
Day/night switch Electromechanical IR-cut filter
Minimum illumination (colour) 0.1 lux
Minimum illumination (IR) 0 lux
Noise reduction > 62 dB
Electronic shutter control PAL: 1/25 s to 1/25,000 sec.
Backlight compensation Yes
Video system PAL
IR LEDs 42
IR range 20 m
Connections Video signal (BNC), power supply (DC)
Power supply 12 V DC
Power consumption Max. 500mA
Operating temperature -20 °C – 60 °C
Humidity Max. 90%
Protection class IP 66
Dimensions (Hx)
134.2×123.9×88.1mm
Weight 800 g
