31
EFFECT
Function Description
POSI/NEGA POSI: Positive display of image
NEGA: Negative display of image
MIRROR OFF: No mirroring of the video image
HORIZONTAL: Horizontal mirroring of the video image
VERTICAL: Vertical mirroring of the video image
ROTATE: Horizontal and vertical mirroring of the video image
DEFAULT Restores all values in the sub-menu to the factory settings
RETURN Back to main menu
PRIVACY MASK
The privacy zone mask can be adapted. The set privacy zone is adapted to the size according to
the zoom factor.
PRIVACY MASK
AREA 1
MASK OFF
START X 16
END X 156
START Y 12
END Y 84
COLOR WHITE
TRANSP 2
MOSAIC ON
DEFAULT ON
RETURN
Note: The grid for the privacy zone setting is 640x360 points over the whole video image. The
minimum size of a zone is 40x30 points. The maximum size of a zone is 640x360 points.
Function Description
AREA Selects the privacy zone to be processed (1–16)
MASK OFF: The selected mask is deactivated.
ON: The selected mask is activated.
START X Horizontal start point
END X Horizontal end point
START Y Vertical start point
END Y Vertical end point
COLOR Colour options for the individual zone:
white, black, red, green, blue, yellow, cyan, magenta
TRANSP Value for the optical transmittance of the colour represented (0–3)
MOSAIC ON: Activated mosaic representation of the selected zone.
OFF: Deactivated mosaic representation of the selected zone.
DEFAULT Restores all values in the sub-menu to the factory settings
RETURN Back to main menu
